Aerated Autoclaved Concrete and ASTM Certification to boost the economical building impacts.

ASTM Specifications and Certifications

TESTING AND APPROVAL



ASTM C1693 - 09e1: Standard Specification for Autoclaved Aerated Concrete (AAC)


Scope

1.1 This specification covers autoclaved aerated concrete (AAC), a cementitious product based on calcium silicate hydrates in which low density is attained by the inclusion of an agent resulting in macroscopic voids, and in which curing is carried out using high-pressure steam.


1.2 The raw materials used in the production of autoclaved aerated concrete are Portland cement or blended cements, quartz sand, water, lime, gypsum or anhydrite, and an agent resulting in macroscopic voids. The quartz sand used as a raw material may be replaced by a siliceous fine aggregate other than sand, and usually is ground to a fine powder before use. Fly ash may be used as a sand replacement. The batched raw materials are mixed thoroughly together to form a slurry. The slurry is cast into steel molds. Due to the chemical reactions that take place within the slurry, the volume expands. After setting, and before hardening, the mass is machine cut into units of various sizes. The units then are steam-cured under pressure in autoclaves where the material is transformed into a hard calcium silicate.


1.3 The values stated in inch-pound units are to be regarded as standard. The values given in parentheses are mathematical conversions to SI units that are provided for information only and are not considered standard.


ASTM C1694-09: Standard Specification for Reinforced Autoclaved Aerated Concrete (AAC) Elements


Scope

1.1 This specification covers reinforced solid elements manufactured from autoclaved aerated concrete (AAC), a cementitious product addressed by Specification C1693. The specification addresses dimensional tolerances, maximum limits for drying shrinkage, requirements for steel reinforcement, and shipping and handling.


1.2 The values stated in inch-pound units are to be regarded as standard. The values given in parentheses are mathematical conversions to SI units that are provided for information only and are not considered standard.


ASTM C1660-10: Standard Specification for Thin-bed Mortar for Autoclaved Aerated Concrete (AAC) Masonry


Scope

1.1 This specification applies to thin-bed mortar for autoclaved aerated concrete (AAC) masonry.


1.2 The testing laboratory performing these test methods shall be evaluated in accordance with Practice C1093.


1.3 The values stated in inch-pound units are to be regarded as standard. The values given in parentheses are mathematical conversions to SI units that are provided for information only and are not considered standard.

What is ASTM Certification?

 The ASTM Certification Program covers products (including materials, processes, and services) and personnel for industries that desire an independent third party demonstration of compliance to standards and/or are facing regulatory pressures to prove compliance to standards .

Learn More
